SM-120B (Bench Type)
SM-120P (Pole Type)
SM-120H (Hanging Type)
Linerless solution & Allergen printing
Many regions require a clear display of nutrition facts and allergen information on product labels. Standardized label sizes do not account for varying lengths of information, which often results in wasted label space. Linerless labels are single continuous labels that are automatically sized to fit the information for each product. Less wasted space means less wasted labels, reduce cost, and make labels more
Floating Clerk
Up to five scales can be networked together, which is useful for price changes and for the floating clerk function, where users can start a transaction on one scale and finish the transaction on another.
Fiscal memory function
A microSD card slot is equipped on the mainboard. Insert a 4GB SD card for fiscal memory. This function complies with the latest European fiscal regulations. Transaction data is also written into fiscal memory, and cannot be erased. 4GB provides storage for up to 10 years, and a PC tool is available to read the data.
Reliable Hardware
The SM-120’s printer gives you more than 330,000 cuts per oil tank, making it virtually maintenance-free. The thermal head uses EPROM; the thermal head’s serial number, accumulated printing length and number of cuts are recorded, and self dot diagnosis is available. All information can be accessed from the cloud. @Label cloud software can also connect with a partner auditing company to send data in the requested format. 60mm printing width with quick printing speeds of up to 110mm/s.
Network connectivity & remote maintenance
FTP and TCPIP protocols allow for ethernet communication with a PC. The DHCP protocol is also supported. The SM-120 can receive remote setting and firmware updates, remote diagnosis, remote programming services, etc. For this scale, the data structure has been changed to CSV format, and users can select both TCPIP and FTP protocols. Firmware updates, spec settings (141 and 142), hardware diagnosis (for 38 components), and PLU programming service can be realized remotely from HQ or DIGI cloud center, helping to reduce service costs. TCPIP and FTP protocols.
- State of the art communications with TCP/IP built in
- Flexible label formatting with full graphic capability
- Image printed on label with .bmp files
- Simple and quick changing between labels using the removable cassette
- Capable of full ingredients and cooking instructions
- Meets Canadian nutrition label requirements
Dimensions
| SM-120 (Bench Type) | 427 x 361 x 146 mm |
| SM-120P (Pole Type) | 361 x 500 x 584 mm |
| SM-120H (Hanging Type) | 342 x 300 x 950 mm |
Weighing
| Capacity | Max 6kg | Max 15kg | Max 30kg |
|---|---|---|---|
| Single Interval 1/ 6,000 | e= 2g | e= 5g | e= 10g |
| Capacity | Max 3/ 6kg | Max 6/ 15kg | Max 15/ 30kg |
| Multi Interval 1/3,000 | e= 1/ 2g | e= 2/ 5g | e= 5/ 10g |
Display
| Operator Display | FSTN type LCD with backlight 32×202 dots |
| Customer display | FSTN type LCD with backlight 32×202 dots |
| Tare Weight display | 4 digits |
| Weight Display | 5 digits |
| Unit Price Display | 6 digits |
| Total Price Display | 7 digits |
| Second Line Display | 25 characters |
General Specifications
| Models |
SM-120B |
SM-120P |
SM-120H |
|
Number of Present Keys |
32 |
56 |
32 |
|
Memory Capacity |
2MB (Expandable up to 8MB) |
||
|
Standard Interface |
RS232C, Ethernet, Cash Drawer control port, AC receptacle |
||
Operating Conditions
| Power Source | AC 176V ~ 264V, 47~63Hz |
| Operating Temperature | -10 °C ~ +40 °C |
| Operating Humidity | 15% ~ 85% RH |
|
Power Consumption |
0.15A |
Labeling
| Label Printing Size (W ｘH) | Max. 60mm x 220mm |
|---|---|
| Paper Width | 60mm for Label 62mm for Receipt |
| Printing Speed-Label | Up To 110mm/s |
